From May 6th to 8th, CME Shanghai International Machine Tool Exhibition, Changzhou Bidefu Booth No. 5B01-1, we sincerely invite you to visit and give guidance.
Changzhou Beidefu specializes in the design and production of power chucks and rotary oil (gas) cylinders. The company has an experienced design team and a production team with strong manufacturing capabilities. It can provide users with high-quality services, and can also design and produce various special fixtures according to different user needs, and install hydraulic chuck systems on various machine tools. Changzhou Bedford has rich manufacturing experience especially in vertical lathe hydraulic chucks, front-mounted pneumatic pipe thread chucks, double-action chucks and rotary cylinders. Changzhou Beidefu will, as always, adhere to the business philosophy of 'technological innovation, manufacturing high-quality products', fully implement quality management, strictly control product quality, continuously improve the service system and product series, and continue to strive to remain a more professional and influential clamp manufacturer and service provider in the country. The company has always pursued the business policy of 'customer first', adhered to the management philosophy of 'quality first', and served customers wholeheartedly. We look forward to continuing to receive support and cooperation from our customers. Three claw pneumatic card
Installation instructions for pneumatic chuck: 1. Take out the connecting sleeve, screw on the screw, and connect it to the tail of the spindle. Use a dial indicator to correct the outer circle and end face runout of the connecting sleeve to control it within 0.05 mm, and tighten the screws. 2. Take out the chuck, wipe it clean with a rag, and use a caliper to measure whether the lathe flange size is consistent with the chuck connection size. If not, complete the flange to the chuck size. 3. Take out the spiral air duct, set the decorative hoop, and install the air duct on the ventilation joint of the chuck. Then use a vise to clamp the clamp and do not damage the air pipe during installation. 4. Use the capsule to wrap the trachea in sections to ensure smoothness, and then mark No. 1 and No. 2 at the end of the trachea. Then use a thin wire to pass the air pipe through the lathe spindle, so that the air pipe passes through the spindle smoothly, and the support chuck moves backward synchronously and is gently buckled on the flange. 5. Take out the screws, fix the chuck on the flange, and measure the cylinder runout ≦0.05. 6. Tighten the air pipe and cut off the excess at the end.
